Ultra-Safe™ EXP Explosion-proof Unit Heater
Our most popular and versatile construction has a broad range of stock designs, special options and the industry’s lowest Ignition Temperature Code rating, 320°F (160°C).
Indeeco’s Ultra-Safe™ EXP explosion-proof unit heater is designed with both safety and versatility in mind and is now available for wet locations too.
Approvals
ULTRA-SAFE™ EXP Features
Optional Wet Location Features
- Washable per IP55
- IP55 Motor
- Type 4 outdoor rated enclosure and optional features
- Meets rain-tight requirements of UL 1004-1
Industry’s Lowest Ignition Temperature Code Rating
T3C, 320°F (160°C)
Dual Overtemperature Protection
With both automatic and manual reset overtemperature cutouts for additional safety.
Nontoxic Propylene Glycol Heat Transfer Fluid
Low 70 PSIG Relief Valve Setting:
This assures that in an emergency, the initial escaping vapor temperature remains below the 320°F (160°C) ignition temperature.
Corrosion Resistant Options
Indeeco offers three constructions suitable for most applications.
- Standard construction for use in dry non-corrosive areas includes: welded steel heat exchanger; powder-coated cabinet.
- A 316 stainless steel construction suitable for Waste Water Treatment Plants includes: 316 stainless steel heat exchanger, headers and tubes with aluminum fins; stainless steel cabinet; corrosion resistant hardware.
- Third construction is suitable for use in Chemical Plants where chlorides are present and includes: Heresite® coated heat exchanger, cabinet, fan blade; corrosion resistant hardware.
Standard Features
Heat Exchanger
Efficient liquid-to-air design utilizes an all welded steel headers and finned tube construction with spiral wound aluminum fins. Industrial grade INDEECO heating elements are immersed in a nontoxic, inhibited, propylene glycol heat transfer fluid that provides freeze protection down to -49°F (-45°C). The heat exchanger is hydrostatically tested at 350 psig. A pressure relief valve provides excess pressure protection and is set at 70 psig.
Fan Motor Assembly
Consists of an explosion-proof motor fitted with an aluminum fan blade. The motor has double- shielded, permanently lubricated ball bearings and automatic reset line breaking thermal overload protection. Motors furnished on standard units operate at line voltage and are prewired to the control enclosure so separate field wiring to the motor is not required. The standard motor is rated for Class I, Groups C and D, Class II, Groups F and G. The minimum operating temperature is -14°F (-25°C) and the minimum storage temperature is -49°F (-45°C). Download the product data sheet for optional motor ratings.
Cabinet/Louvers
Industrial grade, corrosion resistant construction fabricated from beige powder coated 14-gauge galvanized steel. The adjustable louvers have minimum opening safety stops.
Controls
Factory mounted on the unit heater. Standard built-in controls include automatic and manual reset overtemperature cutouts, controlling magnetic contactor, and 24-volt control circuit transformer housed in a NEMA 7, 9 cast aluminum enclosure.
Factory Built-in Options
Wet Location Construction
Heater construction is suitable for IP55 wet locations. Requires either 316 stainless steel corrosion-resistant or dirty duty corrosion-resistant construction option.
316 Stainless Steel Corrosion-Resistant Construction (Waste Water Treatment Plants)
316 Stainless steel heat exchanger with aluminum fins, 316 stainless steel cabinet; aluminum fan blade; cast aluminum NEMA 4, 7, 9 control enclosure; corrosion-resistant hardware; corrosion-resistant protective coated motor, which has passed the ASTM B117 salt-spray test.
Dirty Duty Corrosion-Resistant Construction (Chemical Plants)
Heresite® coated heat exchanger, cabinet and fan blade; cast aluminum NEMA 4, 7, 9 control enclosure; corrosion-resistant hardware; corrosion-resistant protective coated motor which has passed the ASTM B117 salt-spray test.
Disconnect Switch
Factory installed on the unit heater above the control enclosure. This is an inexpensive and positive way to meet NEC/CEC requirements for a disconnecting means within sight of the heater.
Group E (Metal Dust) Construction
Class II, Group E (Metal Dust) Construction Temperature Code T3C, 320°F (160°C). Not available with wet location construction or 600V.
“Warning” Pilot Light
Indicates when the thermal cutouts have tripped and the unit heater needs servicing.
“Heater On” Pilot Light
Indicates when the electric heating elements are energized.
Manual Reset Thermal Cutout with Backup Contactor
A pilot duty manual reset thermal cutout with a backup contactor is provided for independent secondary overtemperature protection. This option cannot be provided if option Code S or V are also specified.
Auto/Fan Selector Switch
A two-position switch wired to the control circuit for auto (automatic heat) and fan only control. This selector switch cannot be provided if option Code M or V are also specified.
Built-In Controls for Remote Auto/Fan Selector Switch
Unit is prewired for field addition of remote auto/fan selector switch. This option cannot be provided if code M or V are also specified.
Adjustable Thermostat
Factory installed and prewired to the control enclosure. Thermostat is adjustable from 50° to 90°F (10° to 32°C) range.
Adjustable Thermostat for Wet Locations
Factory installed and prewired to the control enclosure. Thermostat is adjustable from 40° to 80°F (5° to 25°C) range. Can be specified for all constructions.
120 Volt Control Circuit
Can be provided when required for special external thermostat circuit. This option cannot be provided if option Code S or M are also specified. Nor can both K and L be specified.
Accessories
Mounting Kit
These are available for ceiling, wall and pole mounting.
Remote Thermostat
Type 1 and Type 4 remote wall mounted thermostats are available.
Remote Fan Switch
Type 1 and Type 4 remote wall mounted fan switches are available.
Classifications
- Class I, Divisions 1 and 2, Groups C and D
- Class II, Divisions 1 and 2, Groups E, F and G
- Class I, Zones 1 and 2, Group IIB
- Temperature Code T3C, 320°F (160°C)
Applications
Aircraft Hangars/Service Areas
Chemical Storage/Handling Areas
Coal Preparation Plants
Compressor Stations
Grain Elevators
Oil Refineries and Rigs
Paint Storage Areas
Petrochemical Plants
Sewage Pump Stations/Treatment Plants (Option C1 recommended)
Spray Booths
