Here at Indeeco we have Series EP2 Explosion-proof Division 2 Duct Heaters, let’s check them out!
Standard Construction Galvanized Sheet Metal Frame includes external duct flanges for field mounting, an element terminal enclosure with control and safety components in an integral cast aluminum explosion-proof box.
Three Levels of Safety are provided on every heater:
-automatic reset thermal cutouts
-manual reset thermal cutouts
-airflow interlock with either a fan relay or pressure differential airflow switch
The automatic reset cutout, wired into the control circuit is the primary over-temperature protection. The manual reset operates a separate backup magnetic contactor, independent of the primary over-temperature circuit. The fan interlock relay prevents the heater from being energized unless the fan starter is on.
Our Standard Built-in Control Package includes the following components mounted in a cast aluminum explosion-proof enclosure:
Control Options Two standard control options are available:
Staged Control – Either single or multi-staged through a step controller, which may be built-in or remotely mounted.Solid-State SCR Control – When temperature must be controlled precisely, built-in SCR’s are recommended. They are furnished with field-selected inputs of 2200 ohms, 135 ohms, 0-10 VDC, or 4-20 mA. SCR’s have zero-cross firing to eliminate radio frequency interference.
Complete installation instructions are furnished with each heater. The following are some guidelines:
Indeeco’s attention to detail and rigorous testing give worldwide customers premium products.
Whatever your heating needs are, Indeeco can meet them. Indeeco has been in business for over 85 years and our innovations are reflected in our heating solutions.
For more information on our Series EP2 Explosion-proof Duct Heaters please contact us @ www.indeeco.com or 800-243-8162
